Cnc Stone Bridge Saw For Granite

Cnc Stone Bridge Saw For Granite

Hualong Machinery is a well-known Chinese manufacturer of stone machinery. We offer a wide range of models cnc stone bridge saw for granite, including the 3-axis HLSQ400, 4-axis HKNC450, and 5-axis HKNC500, with a variety of configurations available.
Send Inquiry
Description

Hualong Machinery is a well-known Chinese manufacturer of stone machinery. We offer a wide range of models cnc stone bridge saw for granite, including the 3-axis HLSQ400, 4-axis HKNC450, and 5-axis HKNC500, with a variety of configurations available.

Below is our HKNC825 5-axis cnc stone bridge saw for granite. Welcome to contact us for inquiries

asa

Product Overview



CNC Stone Bridge Saw: HKNC-825 5-Axis CNC Bridge Saw

Equipped with an Italian control system, all main electrical components adopt international first-line brands.



Main Processing Materials



Suitable for cutting marble, granite, sintered stone, quartz stone, engineered stone, concrete, ceramic, etc.



Main Application Fields



Building decoration, home improvement materials, custom furniture, municipal engineering, etc. Typical applications include stone cladding for building exteriors, kitchen and countertop fabrication, dining table and bar top cutting, paving stone cutting for gardens and plazas, and more.

Equipment Functions



*Equipped with a camera system for photo layout and optimized cutting path.

*Fitted with an electric spindle for drilling, letter engraving and other processing.

*The head can rotate 360 degrees.

*The saw blade supports chamfering at any angle from 0° to 90°.

*The worktable can tilt up to 85°.

Italian control system

Blad & electric spindle

photoing

Worktable tilt 85°

product-800-800

product-800-800

product-800-800

product-800-800

Saw Blade Cutting Function Diagram



product-1200-400

Technical Parameters



Name

Unit

HKNC-825

Diameter of saw blade

mm

Φ400-800

Dimensions of working platform

mm

3500×2100

Max. length of horizontal cutting

mm

3500

Max. cutting thickness

mm

290

Power of main motor

mm

650

Max. lifting travel

kw

22

Power of cutter frame reciprocating motor

kw

2

Power of crossbeam shifting motor

kw

1.1

Power of hydraulic station motor

kw

2.2

Power of lifting motor

kw

0.85

Gross power

kw

36.5

Water consumption

m³/h

2

Dimensions(L×W×H)

mm

6800×3400×3900

Gross weight

kg

6500



Customer Cases





2025101820294292128
