The Hualong Machinery HLQY-1600 multi blade block cutter machine serves as the primary block cutting equipment for stone processing plants. It is specially designed for cutting slabs from granite, marble and other types of stone blocks. Featuring high cutting efficiency, stable operation and a high level of automation, this machine is widely adopted by medium and large stone processing factories, making it core equipment for mass production of stone slabs.
multi blade block cutter machine cutters are available in customized models. The standard models include HLSQ-1600, HLSQ-2500 and HLSQ-3000. Equipped with a PLC control system and a heavy-duty frame structure as well as high-precision linear guide rails, the machine has a maximum lifting stroke of 1350 mm. It can complete fully automatic cutting independently, minimizing manual operation and greatly improving processing efficiency.
Technical Parameters
|
NAME |
Unit |
HLQY-1600 |
HLQY-2300/2500 |
HLQY-3000 |
|
Main motor power |
55(4P) |
75/90 (4P) |
90/110 (6P) |
|
|
Max. blade diameter |
1650 |
2300/2500 |
3000 |
|
|
Cross-beam |
A/B |
A/B |
||
|
Cross-beam length A/B |
mm |
7600/8300/9800 |
7600/8300/9800 |
7600/8300/9800 |
|
Longitudinal beam length |
mm |
4000/4500/5000/5500 |
||
|
Lifting stroke |
mm |
800 |
1350 |
1350 |
|
Power of pump motor |
kw |
5.5 |
||
|
Power of stroke motor |
kw |
3/4 |
||
|
Power of vertical motor |
kw |
1.1 |
||
|
Gross power |
kw |
62.3 |
82.3/97.3 |
97.3/117.3 |
|
Gross weight A/B |
kg |
10000 |
13000/14000 |
14000/15500 |
|
Dimensions(L x W x H) |
mm |
8000/8700/10200x 4800/5300/5800/6300x 4500 |
||
Core Parameters
Saw Blade Specification: The maximum diameter of saw blades ranges from Φ1650mm to Φ3000mm, which can be flexibly selected according to slab thickness.
Processing Size: Standard cutting length is 3500mm and cutting width is 2000mm. Two lifting strokes (800mm and 1350mm) are optional to meet the processing requirements of large-size stone blocks.
Power Configuration: For model HLQY-1600, the total installed power is 62.3kW, including a 55kW main motor, a 4kW oil pump motor, a 2.2kW travelling motor and a 1.1kW lifting motor. It delivers sufficient power with reasonable energy consumption.
Machine Body Specification: The machine weight ranges from 10 tons to 15.5 tons. Adopting a heavy-duty frame structure, each model is equipped with a crossbeam of corresponding length, ensuring excellent operational stability.
Application Fields
Suitable for cutting raw stone blocks such as granite, marble and sandstone.
FAQ
Q: Are you a direct manufacturer or a trading company? Can we visit your factory?
A: We are a professional stone machinery manufacturer integrating R&D, production and sales. You are warmly welcome to come and inspect our factory.
Q: What stone machinery do you mainly supply?
A: Multi-blade block saws, 5-axis CNC bridge saws, 4-axis bridge saws, 7-axis robot engraving machines, automatic edge polishing machines, automatic polishing machines, waterjet cutting machines, etc.
Q: What control system is equipped on the machines?
A: PLC control system. It is simple and easy to learn, so operators can be trained quickly.
Q: What official certifications do you have? Are CE and ISO9001 certificates available?
A: Hualong Machinery is a national high-tech enterprise and a "Specialized, Refined, Unique and Innovative" Little Giant enterprise. We hold complete CE and ISO9001 certifications.
Q: Can you send technicians overseas for on-site installation, commissioning and training for foreign buyers?
A: Yes, we provide on-site installation, commissioning and technical training services.
Q: Is equipment customization available?
A: Yes. We can customize the machine model according to the actual size of customers' stone blocks.
Q: What is the production lead time?
A: Normally 30 to 45 days, depending on the machine model and configuration.
Q: How long is the warranty period?
A: We offer a 12-month warranty.
Q: What trade terms do you accept?
A: We accept common trade terms including FOB, CIF and EXW.
